NEBULIZER SPECIFICATIONS




All Burgener Nebulizers use Teflon for the sample passage and for the gas orifice, except for the Mira Mist CE,Enya Mist and X-175 which have Teflon bodies and PEEK sample passage and gas orifice.

Most Burgener Nebulizers are 100% Teflon except for the removable gas fittings, but the PEEK Mira Mist and the Ari Mist use PEEK for the outside body, and Teflon for the inner capillaries.

All Burgener Nebulizers use the patented Enhanced Parallel Path Method of creating a mist. None of our nebulizers have suction, so liquids must be pumped to the nebulizers.


Standard Nebulizers

Model Body
Material
psi
Operating
Pressure
at .8 l/min
Sample Flow
microliters/min
Sample
Capillary I.D.
microns

Nose Length

Nose Diameter

Overall Length

Standard Gas Line

Pluggable
Appropriate
Chamber
Comments
PEEK
Mira Mist
PEEK 35-45 200 - 2500 500 34 mm 6 mm 65 mm 2 mm possible
not likely
All High Salts, Medium Particles, excellent %RSD (< .7%), very good sensitivities and excellent long term stability.
Not appropriate for concentrated acids, some organics.
Teflon
Mira Mist
PTFE 35-45 200 - 2500 500 34 mm 6 mm 65 mm 2 mm possible
not likely
All High Salts, Medium Particles, excellent %RSD (< .7%), very good sensitivities and excellent stability.
Excellent for all acids, all organics.
T 2100 PTFE 30-40 500 - 2500 750 34 mm 6 mm 65 mm 2 mm Nearly Impossible All High Salts, Particles, excellent %RSD (< 1%), very good sensitivities and excellent stability.
Excellent for all acids, all organics.
Ari Mist PEEK 35-45 50 - 1000 225 34 mm 6 mm 65 mm 2 mm possible
not likely
All Medium Salts, NO Particles, good %RSD (< 1%), Excellent sensitivities.

Micro Flow for alcohol, organics: 50 ul/min +
T2002 PTFE 35-45 800 - 2500 500-800 28 mm 6 mm 58.4 mm 1/8", 1/4",
4 mm
available.
No All High Salts, Particles, good %RSD (< 1%), good sensitivities.
Can not plug nebulizer - inner sample passage larger than capillary used to carry sample from pump to nebulizer.



Nano and Micro Low Flow Nebulizers

Model Body
Material
psi
Operating
Pressure
at .8 l/min
Sample Flow
microliters/min
Sample
Capillary I.D.
microns

Nose Length

Nose Diameter

Overall Length

Standard Gas Line

Pluggable
Appropriate
Chamber
Comments
Mira Mist - CE PEEK 75-90 2 - 2500 500 34 mm 6 mm 65 mm 2 mm possible
not likely
All
or
mini
chamber
Designed for CE / ICP / MS. Allows CE capillary to extend to tip. Also runs as excellent nebulizer without CE capillary.
PFA 250 PFA Teflon 50 25 - 1000 250 34 mm 6 mm 65 mm 2 mm possible
not likely
All Medium Salts, small Particles, good %RSD (< 2%), Excellent sensitivities and low flow capable. Ultra Clean PFA construction.
All wetted parts are PFA.
X - 175 Teflon & PEEK 40 50 - 1000 175 34 mm 6 mm 65 mm 2 mm easy All standard Medium Salts, NO Particles, good %RSD (< 1%), Excellent sensitivities.
Designed for ICP/MS low flow applications. Greater stability than Ari Mist HP
Can also do Micro Flow for alcohol, organics: 5 ul/min +
NX - 175 Teflon & PEEK 30 50 - 1000 175 34 mm 6 mm 65 mm 2 mm easy All standard Medium Salts, NO Particles, good %RSD (< 1%), Excellent sensitivities.
Designed for NexION and Bruker/Varian ICP/MS low flow applications with 1.2 L/min gas flow at 50 psi. Greater stability than Ari Mist HP
Can also do Micro Flow for alcohol, organics: 5 ul/min +
Ari Mist HP PEEK 65 5 - 1000 150 34 mm 6 mm 65 mm 2 mm easy All
or
mini
chamber
Medium Salts, NO Particles, good %RSD (< 1%), Excellent sensitivities.
Works with Burgener Mini Chamber - simpler than direct injection with same advantages.
Micro Flow for alcohol, organics: 5 ul/min +
ENYA Mist Teflon 50 0.2 - 50 60 34 mm 6 mm 65 mm 2 mm easy All
or
mini
chamber
Medium Salts, NO Particles, good %RSD (< 2%), Excellent sensitivities but low flow lowers intensities.
Tiny sample passage allows for split flow - pump 30 - 50X what actually arrives in the nebulizer. The rest goes to the drain. Minimizes oxides in ICP/MS.



Special Purpose Nebulizers

Model Body
Material
psi
Operating
Pressure
at .8 l/min
Sample Flow
microliters/min
Sample
Capillary I.D.
microns

Nose Length

Nose Diameter

Overall Length

Standard Gas Line

Pluggable
Appropriate
Chamber
Comments
SS 50 Stainless Steel Requires ~ 2 L/min
at 50 psi
10 - 5,000 1800 2" - 18" 0.125" Varies 1/8" No Special High Temperature, low to high flow. Commonly used for material coatings and nano particle production.
LB 30 PTFE or Peek or Any material Requires ~ 15 L/min
at 40-50 psi
2,000 - 30,000 1000 12 mm 1/4" pipe thread Varies 1/8" No Industrial High Sample Flow, excellent mist.
Runs 2 to 50 ml/min, with optimum from 5 to 35 ml/min.
Designed for industrial applications, not for ICP analysis.
LB 80 PTFE or Peek or Any material Requires ~ 40 L/min
at 40-50 psi
500 - 80,000 3000 100 mm
4"
12 mm
0.5"
Varies 3 mm No Industrial High Sample Flow, excellent mist.
Runs .5 to 80 ml/min, with optimum from 5 to 70 ml/min.
Designed for industrial applications, not for ICP analysis.
LB 100 PTFE or Peek or Any material Requires ~ 50 L/min
at 45-55 psi
1,000 - 100,000 3000 100 mm
4"
12 mm
0.5"
Varies 3 mm No Industrial High Sample Flow, excellent mist.
Runs 1 to 100 ml/min, with optimum from 5 to 80 ml/min.
Designed for industrial applications, not for ICP analysis.


Teflon is a registered trademark of E.I. DuPont De Nemours Company and in all cases in this web page refers to PTFE (PolyTetraFluoroEthylene)
